    AI Overview

    An AI Overview is not available for this searchCan't generate an AI overview right now. Try again later.
    AI Overview
    A Time-to-Digital Converter (TDC) for time-dependent single photon counting (TCSPC)
    measures the precise arrival time of single photons relative to a start signal (like a laser pulse), converting these picosecond-level intervals into digital data to build histograms of photon arrival times, crucial for understanding fluorescence decay, quantum key distribution, FLIM, and LiDAR. TDC designs often use Field-Programmable Gate Arrays (FPGAs) with delay lines for high resolution, allowing for accurate time-tagging even at high rates, with solutions ranging from dedicated modules (like qutools' quTAG or PicoQuant's modules) to custom FPGA implementations.
    How it Works in TCSPC
    1. Start Signal: An excitation pulse (e.g., from a laser) generates a "start" electrical signal.
    2. Photon Detection: A single photon emitted from the sample is detected by a sensitive detector (like a PMT).
    3. Stop Signal: The detected photon creates a "stop" electrical pulse.
    4. Time Measurement: The TDC measures the tiny time difference (
      Δtdelta t
      Δ𝑡
      ) between the start and stop signals.
    5. Digital Conversion: This analog time interval is converted into a digital number.
    6. Histogramming: Repeated measurements are collected, and a histogram is built to show the probability of a photon arriving at a specific time after the start, revealing the sample's decay characteristics.
    Key Features & Implementations
    • Resolution: Picosecond (ps) timing resolution is standard, achieved through coarse/fine counters and tapped delay lines on FPGAs.
    • FPGA-Based: FPGAs offer flexible, cost-effective, high-speed alternatives to ASICs, managing complex timing and high data throughput.
    • Calibration: Essential for correcting inherent TDC non-linearities, often using specialized single-photon techniques to avoid data loss.
    • Dead Time: Critical for avoiding pile-up; good TDCs have short dead times and high count rates (e.g., 12 Mevents/s).
    • Commercial Solutions: Companies like qutools, PicoQuant, Becker & Hickl, and Cronologic provide off-the-shelf TDC modules.
    Applications
    • Fluorescence Lifetime Imaging (FLIM)
    • Quantum Key Distribution (QKD)
    • Coincidence Measurements
    • Time-of-Flight (ToF) Mass Spectrometry
    • A time-to-digital converter with steady calibration through single- ...
